Trade-Wind® P7200 Series 42-inch stainless steel pyramid style outdoor wall mounted range hood provides exceptional ventilation for outdoor cooking spaces. Built with durable weather-resistant materials, it efficiently removes smoke, heat, and odors while adding sleek modern style and reliable performance to premium outdoor kitchens.Read More
Recessed controls and LED lights
Buttons and light glare hidden from the front
Two LED lights brighten cooking area (three on 48”,60”, and four on 72” model)
Commercial grade stainless steel (#304 grade) and galvanized steel construction
CFM and sound tested by Energy Systems Laboratory at Texas A&M University
Rubber-mounted motor & large, squirrel-cage blowers reduce sound and vibration
3-speed motor control reduces blower and air movement sound
Double bank of baffle filters allows for the largest active capture area in
outdoor hoods. Generously proportioned 32” depth of hood bottom, 15′′ depth at top, 24′′ high, provides an exceptional capture area.
Cool touch knarled knobs for easy control
All 24” bodied hoods easily convert from vertical discharge to horizontal at job site
General Specs | |
| Color | Stainless Steel |
| Color/Finish Name | Stainless Steel |
| Range Hood Type | Wall Mounted |
| Ventilation Type | Ducted |
| Vent Location | Top |
| Bulb Type | LED |
| Maximum CFM | 1200 |
| Range Hood Features | Light |
| Outdoor Approved | Yes |
| Appliance Fit Width (in.) | 42 |
| Width (in.) | 42 |
| Product Weight (lbs.) | 174 |
| Collection | P7200 |
| Series | P7200 |
| Voltage | 120 |
| Amp | 15/20 |
| Frequency | 60 |
Specifications | |
| Models | 36”, 42”, 48″, 60″ & 72″ |
| CFM | Two or four internal sealed motors deliver 1200 CFM or 2300 CFM Optional in-line blowers deliver 1266 CFM |
| Material | Heavy gauge commercial stainless steel (#304 grade, 22-gauge) Dimmable 50 watt halogen lights |
| Filters | Four 12” by 14” baffle filters improve performance (six filters on the larger model) Design of the stainless steel commercial baffle filters adds a professional appearance and improves the performance |
| Installation | Generously proportioned 32” depth of hood bottom, 15″ depth at top, 24″ high, provides an exceptional capture area |
